配件料號(hào)：
| 型號(hào)： | RAC210 | ||
| Articleno. | Designation | Articleno. | Designation |
| 721682 | Tool body | 710911 | Ball Φ 4 |
| 712269 | Body cover | 711974 | Seeger ring JV 22 |
| 711684 | Cylinder bottom | 710902 | Seeger ring 16 UNI 7435 |
| 721685 | pneumatic piston | 711721 | Gasket B 110078/1/B/NEO |
| 711686 | Connector | 711722 | Gasket B 094063/B/NEL |
| 721689 | Oleodynamic cylinder | 710577 | Gasket B 086055 |
| 711690 | Stem | 711341 | Gasket TS 14-22-5,8/L |
| 711691 | Silencer | 711727 | Screw TSEL M4 x 8 UNI 5933 |
| 711692 | Screw M7x18 | 711728 | Gasket 0R 2-16 |
| 711693 | Dampener | 711730 | Gasket OR 2-119 |
| 711694 | Lower coil | 710931 | Gasket 0R 5-615 |
| 711695 | Threaded sleeve | 710367 | Gasket OR 2-8 |
| 721698 | Valve body | 710376 | Gasket OR 2-9 |
| 711700 | Upper coil | 710918 | Gasket OR 2-5 |
| 711701 | Upper valve bot | 710919 | Gasket OR 2-4 |
| 711702 | Plate | 710003 | Gasket 0R 5-052 |
| 711703 | Valve body | 711061 | Gasket 0R 5-614 |
| 711704 | Valve piston | 711731 | Gasket 0R 2-18 |
| 711705 | Push-button | 711732 | Gasket 0R 2-118 |
| 710839 | Oil tank plug | 710916 | Gasket 0R 2-15 |
| 711706 | Nails container | 710258 | Gasket 0R 5-612 |
| 711707 | Container connector | 711734 | Gasket OR 2-232 |
| 711708 | Container screw | 711735 | Gasket OR 2-40 |
| 711709 | Spring guide connection | 711092 | Key 5 mm |
| 711711 | Piston return spring | 710342 | Gasket 0R 2-17 |
| 711712 | Oleodynamic Piston | 711933 | Seeger ring JV 24 |
| 711713 | Spacer | 721715 | Cone holder(assembly) |
| 711714 | Front connector | 712159 | Protection bottom |
| 711716 | Clamps return spring | 712003 | Cap |
| 711717 | Clamps opener | 712132 | Rotating connector |
| 711718 | Clamps holding cone | 741702 | Plate Kit |
| 711719 | Head carrying nozzle | 711702 | Plate |
| 711720 | Key | 711727 | Screw TSEL M4 X 8 UNI 5933 |
| 717010 | Nozzle for rivet Φ4, 8 AL. | 741713 | Spacer Kit |
| 717008 | Nozzle for rivet Φ 2, 4÷3,4 | 711713 | Spacer |
| 717009 | Nozzle for rivet Φ4 | 710902 | Seeger ring 16 UNI 7435 |
| 717028 | Nozzle for rivet Φ2.4 | 711933 | Seeger ring JV 24 |
| 710854 | Balancer hook | 741717 | Clamps opener Kit |
| 721387 | Oil container | 711716 | Clamps return spring |
| 711778 | Clamps | 711717 | Clamps opene |
| 721775 | Suction tube | 741705 | Push-button Kit |
| 711815 | Ball Φ3,5 | 711705 | Push-button |
| 710906 | Hermetic washer 400-020-4490 | 711726 | Plug Φ2 x20 UNI 1707 |
| 711726 | Plug B 2x 20 UNI 1707 | ||
