配件料號(hào)：
| Model No. R1A1 | |
| Code | Parts Name |
| 10027 | Nosepiece 2.4 (3/32) |
| 10028 | Nosepiece 3.2 (1/8) |
| 10029 | Nosepiece 4.0 (5/32) |
| 10030 | Nosepiece 4.8 (3/16) |
| 64055 | Frame Head 'CJM' |
| 10116 | Jaw Case Head |
| 10281 | Ultra Jaws (pair) 'M' |
| 63410 | Jaw Pusher |
| 10150 | O-ring P6 |
| 64875 | Guide Tube SUS |
| 63222 | Jaw Pusher Spring |
| 10219 | O-ring P9 |
| 63195 | Oil Piston |
| 13012 | B-ring P9 |
| 63213 | Bleed plug |
| 63209 | Sealing Washer |
| 63207 | Vacuum Stop Button |
| 64874 | Frame 'A' |
| 63204 | Switch |
| 10454 | O-ring P4 |
| 63203 | Valve Core |
| 63226 | Barb Elbow for Soft Tube |
| 63211 | Urethane Tube 70 |
| 43732 | Barb Coupling for Soft Tube |
| 63210 | Urethane Tube 87 |
| 63247 | Cross Recessed Pan Head Screw M3x3 |
| 10128 | O-ring P12 |
| 10129 | B-ring P12 |
| 29664 | O-ring S4 |
| 63205 | Vacuum Stop Valve |
| 63212 | Urethane Tube 153 |
| 10180 | O-ring P22 |
| 10181 | B-ring P22 |
| 63187 | Oil Piston Flange |
| 63194 | O-ring P8 (1B) |
| 64399 | Oil Piston Backward Axis 'A' |
| 63241 | Return Spring IN |
| 63242 | Return Spring OUT |
| 63243 | O-ring S25 |
| 64405 | Frame Cap 'A' |
| 63237 | Tank Joint |
| 64402 | Outer shaft of frame cap |
| 63252 | Tank Case Sponge |
| 63231 | Screw for inner surface of tank case |
| 63230 | Inner surface of tank case |
| 63215 | Tank Case |
| 63234 | O-ring S36 |
| 22040 | Caution Label |
| 10276 | O-ring S5 |
| 63250 | Cross recessed pan head screw M3x6 |
| 63251 | Tapping Screw for synthetic resin M3x12 |
| 63263 | Grip Cover LR |
| 63227 | Trigger |
| 63968 | Silencer Sponge |
| 63186 | E-type Retaining Ring 8 |
| 63184 | Rotary Joint |
| 63185 | Spool Connector |
| 10336 | O-ring P8 |
| 63180 | O-ring S9 |
| 64409 | Hex Socket Head Cap Screw M5x10 |
| 63245 | Stop screw mass production |
| 63183 | Air Valve Head Retainer |
| 63979 | Air Valve Head |
| 63181 | O-ring SS7.5 |
| 63174 | Air Valve |
| 12114 | O-ring S7 |
| 64873 | Cylinder Cap 'A' |
| 63175 | Spool Cap |
| 63969 | O-ring SS9.5 |
| 63182 | O-ring SS9 |
| 63177 | Valve Cap |
| 63228 | Frame Fixing Nut |
| 63178 | Cushion Rubber |
| 63170 | Air Piston Set |
| 63244 | O-ring 0670G |
| 63220 | Cylinder Cup |
| 61075 | Warning Label |
| 12120 | O-ring P5 |
| 10151 | O-ring S10 |
| 64054 | Jaw Case 'CJM' |
| 10220 | O-ring S6 |
| 64403 | Inner shaft of frame cap |
| 64400 | Shutter Lever |
| 64406 | Ball Chain |
| 64401 | Shutter Body |
| 64404 | Helical torsion spring of shutter |
| 64410 | Hex Socket Head Cap Screw M3x7 |
| 29187 | Crescent type Retaining Ring 21 |
| 64871 | Bush |
| 63960 | Air Valve Head Retainer R1A2 |
| 63961 | Air Valve Head Rock Plate |
| 64598 | Frame Head Seal |
| 63277 | Tank Case Unit |
