配件料號：
| Model No. R1A2 | |
| Code | Parts Name |
| 10216 | Nosepiece 4.8 (3/16) |
| 10226 | Nosepiece 6.4 (1/4) |
| 63993 | Frame Head |
| 63990 | Jaw Case |
| 10493 | Ultra jaws (pair) 'H' |
| 63991 | Jaw Pusher |
| 10337 | O-ring P10A |
| 63992 | Jaw Pusher Spring |
| 63959 | Jaw Case Lock Washer |
| 63982 | Oil Piston |
| 12194 | B-ring P12.5 |
| 12193 | O-ring P12.5 |
| 63213 | Bleed plug |
| 63209 | Sealing Washer |
| 63207 | Vacuum Stop Button |
| 63999 | Frame |
| 63204 | Switch |
| 10454 | O-ring P4 |
| 63203 | Valve Core |
| 63226 | Barb Elbow for Soft Tube |
| 63211 | Urethane Tube 70 |
| 43732 | Barb Coupling for Soft Tube |
| 63210 | Urethane Tube 87 |
| 63998 | Hydraulic packing PS14 |
| 10435 | B-ring P14 |
| 29664 | O-ring S4 |
| 63205 | Vacuum Stop Valve |
| 63212 | Urethane Tube 153 |
| 12437 | O-ring P26 |
| 12438 | B-ring P26 |
| 64000 | Oil Piston Flange |
| 10185 | O-ring S24 |
| 64597 | Oil Piston Backward Axis 'A' |
| 63966 | Return Spring |
| 10336 | O-ring P8 |
| 29727 | O-ring S32 |
| 64413 | Frame Cap 'A' |
| 63964 | Tank Joint |
| 64595 | Outer shaft of frame cap |
| 63996 | Tank Case Sponge |
| 63231 | Screw for inner surface of tank case |
| 63994 | Inner surface of tank case |
| 63972 | Tank Case |
| 63995 | O-ring S56 |
| 22040 | Caution Label |
| 10276 | O-ring S5 |
| 63250 | Cross recessed pan head screw M3x6 |
| 63251 | Tapping Screw for synthetic resin M3x12 |
| 63263 | Grip Cover LR |
| 63227 | Trigger |
| 63968 | Silencer Sponge |
| 63186 | E-type Retaining Ring 8 |
| 63184 | Rotary Joint |
| 63997 | Spool Connector |
| 63180 | O-ring S9 |
| 63967 | HexagonSocketHeadCapScrew M5x15 |
| 63977 | Stop screw mass production |
| 64880 | Air Valve Head Retainer 'A' |
| 63979 | Air Valve Head |
| 63181 | O-ring SS7.5 |
| 12114 | O-ring S7 |
| 12120 | O-ring P5 |
| 63978 | Air Valve |
| 63961 | Air Valve Head Lock Plate |
| 63976 | Cylinder Cap |
| 63175 | Spool Cap |
| 63969 | O-ring SS9.5 |
| 63182 | O-ring SS9 |
| 63177 | Valve Cap |
| 63962 | Valve Cap Retainer |
| 63963 | Frame Fixing Nut |
| 63987 | Cushion Rubber |
| 63986 | Air Piston Set |
| 40509 | O-ring G95-4D |
| 63988 | O-ring S15 |
| 64003 | Exhaust Valve Case |
| 64005 | Exhaust Valve Spring |
| 64004 | Exhaust Valve |
| 64006 | CR-type Retraining Ring 16 |
| 63973 | Cylinder Cup |
| 61075 | Warning Label |
| 64596 | Inner shaft of frame cap |
| 64411 | Shutter Lever |
| 64412 | Ball Chain |
| 64401 | Shutter Body |
| 64594 | Helical torsion spring of shutter |
| 64410 | Hex Socket Head Cap Screw M3x7 |
| 29187 | Crescent type Retaining Ring 21 |
| 64598 | Frame Head Seal |
| 63956 | Tank Case Unit |
